5-IAI

5-IAI

5% Aqueous HAuCl4

reagent thumbnail 1
reagent 1
reagent thumbnail 2
reagent 2
reagent thumbnail 3
reagent 3
reagent thumbnail 4
reagent 4

5-IAI and gold based reagents all give similar crystals that differ in thickness and color. With aqueous gold chloride reagent form long, thick yellow blades with angled edges. 5μg of the substance dissolved in water when mixed with gold chloride gives the most reliable formation. The blades are very bright under crossed polars and can appear yellow to blue depending on the orientation. Also formed along the edges of the drop is a thick leafy crust that appears a light purple under crossed polars.

5% HAuCl4 in 1:2 concentrated H2SO4: H2O

reagent thumbnail 5
reagent 5
reagent thumbnail 6
reagent 6
reagent thumbnail 7
reagent 7
reagent thumbnail 8
reagent 8

In the acidic gold chloride reagent, 5-IAI forms distinct long blades with serrated edges. The blades are generally branched with one long blade and shorter branches. The blades appear blue to light purple to white under cross polars.

IR Spectrum - 5% HAuCl4 in 1:2 concentrated H2SO4: H2O

Gold Bromide (HAuBr4)

reagent thumbnail 9
reagent 9
reagent thumbnail 10
reagent 10
reagent thumbnail 11
reagent 11
reagent thumbnail 12
reagent 12

Gold bromide reagent is the best reagent for this substance. The crystals formed are thick, red blades with serrated edges and sharp triangular heads. The crystals grow reliably and fully in 15 -20 minutes but do not grow in large numbers.

Platinic Chloride (H2PtCl6)

reagent thumbnail 13
reagent 13
reagent thumbnail 14
reagent 14
reagent thumbnail 15
reagent 15
reagent thumbnail 16
reagent 16

The crystals with platinum based reagents for 5-IAI are not as characteristic with the gold based reagents. The reactions observed with aqueous platinic chloride very small clusters or light leafy blades. Platinic chloride is not a good test for 5-IAI.

Platinic Bromide (H2PtBr6)

reagent thumbnail 17
reagent 17
reagent thumbnail 18
reagent 18
reagent thumbnail 19
reagent 19
reagent thumbnail 20
reagent 20

5-IAI and platinic bromide make very light feathery X-shaped faint yellow crystals. The crystals appear white to bright yellow under crossed polars. The crystals are suspended in solution and are best photographed with a cover slip.
